Netgate 6100 MAX pfSense® Security Gateway Appliance

The Netgate 6100 MAX Security Gateway is a high-performance, future-proof solution for UK businesses and professionals who demand scalable networking, advanced security, and silent operation.

Powered by pfSense® Plus software, the 6100 MAX offers:

• Quad-core Intel Atom C3558 @ 2.2 GHz with AES-NI & QAT acceleration for secure VPN and encryption.
• 8 GB DDR4 RAM and 128 GB NVMe SSD storage for fast, reliable operations.

• Flexible port configuration: 2 × 10 GbE SFP+, 2 × 1 GbE combo, and 4 × 2.5 GbE LAN.

• Enterprise-grade throughput with up to 18 Gbps routing, 10 Gbps firewalling, and 1.77 Gbps IPsec VPN.
• Expansion-ready with dual M.2 slots and Mini-PCIe for LTE, Wi-Fi, or storage upgrades.

• Fanless, compact design, perfect for offices, retail, and professional labs.

• Fully UK certified (CE, UKCA, FCC, RoHS, UL).

With no hidden licensing fees and lifetime pfSense® Plus updates included, the Netgate 6100 MAX is ideal for SMEs, managed service providers, and enterprises looking for a reliable, future-proof firewall and router.

📊 Specifications

• Processor: Intel Atom® C3558 Quad-Core @ 2.2 GHz with AES-NI & QAT
• Memory: 8 GB DDR4 RAM
• Storage: 128 GB NVMe M.2 SSD
• Networking Ports:
  • 2 × 10 GbE SFP+
  • 2 × 1 GbE RJ-45/SFP combo
  • 4 × 2.5 GbE
• Performance:
  • Firewall throughput: up to 10 Gbps
  • Routing throughput: up to 18 Gbps
  • IPsec VPN: up to 1.77 Gbps (AES-GCM-128 with QAT)
• Expansion: 2 × M.2 slots (Key-B), 1 × Mini-PCIe slot
• I/O: RJ45/micro-USB console, 2 × USB 3.0
• Cooling: Fanless, silent passive cooling
• Certifications: CE, UKCA, FCC, RoHS, UL
